65Mn SK5 harden and tempered spring steel strip /strap

  • Grade ::1.65Mn,SK3,SK5,SK7,1065,1095 ,ETC;
  • Thickness::0.08mm-4.0mm
  • Width::10mm-800mm
  • Edge::slit, sheared, square, rounded,etc;
  • Hardness::Soft strip: HV190, Hardened and tempered process (29-55HRC),anneal-ed process (max 19HRC)
PRODUCT DETAILS

tempered spring steel striphardened spring steel strip

Product Name

Spring steel strip /Spring Steel Strap/Spring Steel Band

Material

657065Mn70Mn60SI2CrA60Si2CrVA55CrVA,

SK3SK5SK7S55CS65CSK85SK4SK85T8AT12AT10A,etc;

C67ECK67C75ECK75C85ECK8551Si755Si756Si765Si771Si7UP3SUP6SUP7SUP9SUP9ASUP10sae1050,sae1055,sae1060,sae1065,sae1070,sae1075,etc

Thickness

0.08mm-4.0mm

Width

10mm-800mm or cutting according customer's requests;

Standard

BS,ASTM,JIS,GB,DIN,AISI Standard,etc

Surface

Yellow,Grey, blue, bright, bright & Grey, bright & blue,polished,black ,etc

Edge

slit, sheared, square, rounded,etc;

Process

Hardened (quenched) and tempered,annealed,etc;

Hardness

Soft strip: HV190
Hardened and tempered process (29-55HRC) and  anneal-ed process (max 19HRC).

Or as customer's requirement

Package

PVC film+ waterproof Kraft  paper + strong wooden case /Pallets or according customer's request;

Features

The chemical compositions helps spring steel to endure significant bending or twisting and return to its original shape without deforming.

Application

Spring Steel is widely in the motor vehicle industry and many general engineering applications. It is suitable for applications that require high strength and toughness. Typical applications include crankshafts, steering knuckles, gears, spindles and pumps,etc;

Delivery Term

EXW, FOB, CFR, CIF, DDU.

Note

OEM / ODM / Buyer Label accepted
